Reasonable zoning and distribution of hot air temperature and air volume, advanced sealing structure;
The variable frequency and speed distribution system can scientifically set the material layer thickness to ensure product moisture uniformity;
Nylon mesh belt structure or stainless steel mesh plate structure is optional, which is beneficial to drying materials of various particle sizes;
The steam consumption per ton of finished product is 170-210kg/the natural gas consumption per ton of finished product is 11.5~15m³.
Moisture uniformity can be controlled at ±0.5%;
The drying area of the dryer is divided into separate zones. (Temperature and wind speed in each area can be automatically adjusted to reduce the energy consumption of the dryer and greatly improve the moisture drying uniformity).
Steam or natural gas can be selected as the heat source to meet the needs of different customers.
Automatic adjustment of parameters for different kinds of feeds;
Easy to operate, ensure customer product quality.
| Model | Capacity(t/h) | Drying Area(㎡) | Power(kw) | Precipitation Scope% |
| SHGW120*2 | 1.5-2.5 | 20 | 28 | 15 |
| SHGW180*2 | 3-4 | 30 | 36 | 15 |
| SHGW240*2 | 4-5 | 40 | 48 | 15 |
Before building this production line, the customer has a premix production line for commercial. After several times visiting, our technical team surveyed and mapped the site, and designed customized solutions according to the needs of customers. ..
